Ideal for clamping angle channels with wide mouth and deep jaw. GRIP PLIERS

Max Dimensions (mm) Qty./
Models applicable Carton Weight
(g)
dia. (mm) T A B L (Generally)
VPC-150 VPC-150 30 83 58 56 179 3 260
VPC-300 70 140 100 80 287 3 760
VPC-450 185 160 103 260 443 1 1090

Example
VPC-300
T A

B
L
VPC-450

Inclined objects can be clamped with the free clamping unit. GRIP PLIERS

Max Dimensions (mm) Qty./
Models applicable Carton Weight
(g)
dia. (mm) T A B L (Generally)
VPCV-150 VPCV-150 25 85 60 44 180 3 255
VPCV-300 60 151 102 69 290 3 755
VPCV-450 150 160 108 233 455 1 1145

VPCV-300
T A

B
L
VPCV-450

Ideal for welding and riveting operations. GRIP PLIERS

Dimensions (mm) Qty./
Models Carton Weight
T A B L (Generally) (g)
VPW-250 79 28 72 228 2 635

Example
T B
VPW-250 A
L

Ideal for bending work and temporary fixing. GRIP PLIERS

Dimensions (mm) Qty./
Models Carton Weight
T T1 T2 L (Generally) (g)
VPM-200 58 74 26 194 2 470

VPM-200 T
T2
T1 L

CAUTION
374 ● Jaw opening span of grip pliers can be adjusted freely, but if the tool is forced to do heavier duty job than it is intended it may release work accidentally.
Confirm if the work is surely locked.
