P. 190

SB1A03CR ・ SB1C-CR

■ SUPER CARBIDE BUR
(Cylindrical Corner R Cut Shape)

Features

● The corners of the bur tip are rounded, providing a
better processing control, a wider processing range
D D1
and allowing rounded corner processing.
● Avoids bur tip chipping.
L1
R L ● Shows its cutting ability from the beginning of
processing, and makes also ﬁ ne ﬁ nish.
Corner radius shape Corner radius shape

MICRO AIR GRINDERS & CARBIDE BURS

Micro air
grinders SB1C06CR
■ Shank diameter D1φ3mm ★ marked items : all carbide ■ Shank diameter D1φ6mm ★ marked items : all carbide
Item No. Size （mm） Item No. Size （mm）
(W. cut) L L1 D Corner R (W. cut) L L1 D Corner R
SB1A03CR★ 38 14 3 0.7R SB1C04CR★ 50 18 6 1.3R
Super
carbide burs SB1C05CR 64 20 8 1.5R
SB1C06CR 64 19 9.5 1.5R
SB1C08CR 70 25 12.7 2R
SB1C09CR 70 25 16 2.6R

SB6CRSH
Corner radius shape
■ SUPER CARBIDE BUR SET
(Cylindrical Corner R Cut Shape)

Features
● The corners of the bur tip are rounded, providing a
better processing control, a wider processing range
and allowing rounded corner processing.
● Avoids bur tip chipping.
● Shows its cutting ability from the beginning of
processing, and makes also ﬁ ne ﬁ nish.
● Plastic case as standard acc.

■ Shank diameter D1φ6mm (W. cut) 5pcs-set
Set item No. Set details
SB6CRSH SB1C04CR・SB1C05CR・SB1C06CR・SB1C08CR・SB1C09CR
