SW-N

D ■ POWER PUSHER

Example of use Features
H
● Can be widely used as a compact high power jack.
● Can be set vertically, horizontally, diagonally, etc., in any direction.
● The piston is using a spring back method, so that when the screw is
L loosened, the position automatically gets down even with no load.
● When rusted or burned gears and pulleys are hard to get removed, use the
SW8N
power pusher as shown in the example of use. The hydraulic force of the
power pusher enables easy removing operation.
Size （mm） Applicable puller Max. load N.W.
Item No.
Stroke L H D Gear puller Shock speed puller （kN） （kg）
SW8N 15 172〜223 88〜103 22 8〜24 8・12 80 1.6
HYDRAULIC TOOLS
SW16N 15 210〜284 98〜113 25 18・24 12 160 2.7
＊ For the applicable gear puller, please refer to the gear puller category (P.156～161)
S
S

cylinder
cylinder adaptor
adaptor
GLP T H GTP T H
Hydraulic D GLP10 D
cylinders ■ 2-CLAW ■ 3-CLAW GTP12
HYDRAULIC PULLER SET HYDRAULIC PULLER SET

Feature ● Easy to remove rusted or burned gears and Features ● Easy to remove rusted or burned gears and
pulleys with hydraulic power. pulleys with hydraulic power.
Hydraulic Accessories ● The setting is more stable with 3 claws.
pumps, ● Ratchet wrench with grip (RG), each 1 piece
hydraulic Accessories ● Ratchet wrench with grip (RG), each 1 piece
hoses Size（mm）
H S Max. Set Size（mm）
Item D T Claw reaching length Forcing Forcing load N.W.
No. screw screw Cylinder （kN）（kg） Item D T H S Forcing Max. Set
Pulled Pulled object width Cylinder adaptor external stroke Claw reaching length Forcing load N.W.
Power hex. width dia. No. screw screw Cylinder
pushers, object dia. when D is at max. L in use S in use across fl ats Pulled Pulled object width Cylinder adaptor external stroke （kN）（kg）
hydraulic hex. width dia.
puller sets, GLP10 100〜250 125 125 150 30 28 50 100 16 object dia. when D is at max. L in use S in use across fl ats
pipe
benders GLP12 120〜300 170 175 200 32 32 50 100 19 GTP10 100〜250 125 125 150 32 32 50 100 20
GLP15 150〜375 185 180 210 41 38 50 140 27 GTP12 120〜300 170 175 200 32 32 50 100 24
GLP18 180〜450 200 220 250 46 44 50 140 30 GTP15 150〜375 185 180 210 41 38 50 140 35
GLP24 280〜600 175 300 ー 46 44 50 230 63 GTP18 180〜450 200 220 250 46 44 50 140 42

■ 90° bend
SPB1025NPS
SPB-NPS ■ Pull-up
bend
SPB1025N
■ HYDRAULIC PIPE BENDER ■ Off set
PUMP SET (Manual Type) bend SPB-N

Features ● For bending (up to 90° ) thick (JIS standards) stainless ■ PIPE BENDER Note : ( ) sizes
steel pipe, gas pipe, water pipe. (Hydraulic Type) for SPB520N
● The attachment bendshoe ensures accurate bending
without damaging the pipe.
Accessories ● Attachment bendshoes : ■ Applicable pipe Feature ● Adapted to our hand-operated hydraulic pump and hose.
SPB520N : 10AN, 15AN, 20AN thickness Accessories ● Attachment bendshoes : ● Hex key wrench
SPB1025N : 15AN, 20AN, 25AN 10A＝min. 2.3ｍｍ SPB520N : 10AN, 15AN, 20AN for attachment
● Hex key wrench for attachment 15A・20A＝min. 2.8ｍｍ SPB1025N : 15AN, 20AN, 25AN fi xing (4mm)
fi xing (4mm) 25A＝min. 3.2ｍｍ Can be used only for tubes of exact external diameter.
Depending on the pipe material or thickness, the bending may not be accurate.
Can be used only for tubes of exact external diameter.
Depending on the pipe material or thickness, the bending may not be accurate.
Applicable pipe Bending Max. allowable Cylinder
Set details item No. Item No. size name capacity （kN） pressure stroke （mm）
Set item No.
Bender Pump Attachment bendshoe.
SPB520N 10A・15A・20A 50 70MPa 127
SPB520NPS SPB520N HP900N SPB10AN・15AN・20AN
SPB1025N 15A・20A・25A 100 70MPa 150
SPB1025NPS SPB1025N HP900N SPB15AN・20AN・25AN
Bending radius （mm） N.W.
Item No.
Applicable pipe Bending Max. allowable Set N.W. （kg）
Set item No. 10A 15A 20A 25A
size name capacity （kN） pressure （kg）
SPB520N R50 R50 R50 7.5
SPB520NPS 10A・15A・20A 50 70MPa 18
SPB1025N R50 R50 R70 12.0
SPB1025NPS 15A・20A・25A 100 70MPa 23
＊ N.W. includes SPB20AN or SPB25AN on each bender.
