扳手

®
Flank Drive 梅开扳手

短扳手，mm OEXSM719 OEXSM710B*
OEXSM714K
A B C D LW12E
E
6 OEXM6B GOEXM6B 10 13 5 4 113 • •
7 OEXM7B GOEXM7B 11 15 5 4 118 • •
8 OEXM8B GOEXM8B 13 17 6 4 123 • •
9 OEXM9B GOEXM9B 14 19 6 5 128 • •
10 OEXM10B GOEXM10B 15 21 7 5 133 • • •
11 OEXM11B GOEXM11B 17 23 8 6 138 • • •
12 OEXM12B GOEXM12B 18 25 8 6 142 • • •
GOEXM17B 13 OEXM13B GOEXM13B 20 27 9 6 148 • • •
14 OEXM14B GOEXM14B 21 29 9 7 152 • • •
15 OEXM15B GOEXM15B 22 31 10 7 157 • • •
16 OEXM16B GOEXM16B 24 33 10 7 162 • • •
17 OEXM17B GOEXM17B 25 35 11 8 167 • • •
18 OEXM18B GOEXM18B 27 37 12 8 172 • • •
19 OEXM19B GOEXM19B 28 39 12 9 177 • • •
20 OEXM20B — 30 41 13 9 182 •
21 OEXM21B — 31 43 13 9 186 •
22 OEXM22B — 33 46 14 10 192 •
23 OEXM23B — 34 47 14 10 197 •
OEXSM710B 24 OEXM24B — 35 49 15 11 201 •
工具袋 C1402
®
ASME B107.100 套件包括储物盘

短扳手，In. OEXS721 OEXS715K
OEXS709B*
A B C D E
GOEX200B 1/4 OEX080B GOEX080B 13/32 17/32 3/16 5/32 4 17/32 • •
9/32 OEX090B — 7/16 19/32 7/32 5/32 4 21/32 • •
5/16 OEX100B GOEX100B 1/2 21/32 7/32 5/32 4 27/32 • • •
11/32 OEX110B GOEX110B 17/32 23/32 1/4 3/16 5 • • •
3/8 OEX120B GOEX120B 19/32 25/32 1/4 3/16 5 1/8 • • •
7/16 OEX140B GOEX140B 21/32 29/32 5/16 7/32 5 7/16 • • •
1/2 OEX160B GOEX160B 3/4 1 1/16 11/32 1/4 5 3/4 • • •
9/16 OEX180B GOEX180B 27/32 1 5/32 3/8 9/32 6 1/16 • • •
5/5 OEX200B GOEX200B 15/16 1 5/16 13/32 9/32 6 11/32 • • •
11/16 OEX220B GOEX220B 1 1/32 1 13/32 7/16 5/16 6 21/32 • • •
3/4 OEX240B GOEX240B 1 1/8 1 9/16 15/32 11/32 6 31/32 • • •
13/16 OEX260B GOEX260B 1 3/16 1 21/32 17/32 3/8 7 9/32 • •
7/8 OEX280B GOEX280B 1 9/32 1 13/16 9/16 3/8 7 9/16 • •
15/16 OEX300B GOEX300B 1 3/8 1 29/32 19/32 13/32 7 7/8 • •
1 OEX320B GOEX320B 1 15/32 2 1/32 5/8 7/16 8 3/16 • •
1 1/16 OEX340B — 1 9/16 2 5/32 21/32 15/32 8 17/32 •
1 1/8 OEX360B — 1 5/8 2 5/16 11/16 1/2 8 27/32 •
1 3/16 OEX380B — 1 23/32 2 13/32 23/32 1/2 9 1/8 •
1 1/4 OEX400B —
OEXS715K OEXS709B 1 5/16 OEX420B — 1 13/16 2 9/16 3/4 17/32 9 7/16 • •
9/16
3/4
9 3/4
1 29/32 2 21/32
1 3/8 OEX440B — 2 2 13/16 3/4 19/32 10 1/16 •
工具袋 C1505
®
ASME B107.100 套件包括储物盘
长扳手，mm OEXLM710B
A B C D E
10 OEXLM10B 15 21 7 5 186 •
11 OEXLM11B 17 23 8 6 203 •
12 OEXLM12B 18 25 8 6 218 •
13 OEXLM13B 20 27 9 6 234 •
14 OEXLM14B 21 29 9 7 250 •
15 OEXLM15B 22 31 10 7 266 •
16 OEXLM16B 24 33 10 7 282 •
17 OEXLM17B 25 35 11 8 298 •
18 OEXLM18B 27 37 12 8 314 •
OEXLM710B 19 OEXLM19B 28 39 12 9 330 •
ASME ® B107.100 套件包括储物盘
