T-SHAPE

Wrench Stands
AWSTAND Storage Stand for L-Shaped/T-Shaped Wrenches
• Mounting holes on top and bottom of stand provide many mounting locations
• Another AWSTAND can be added for increased storage options
™
• Stands can mount to a Slots-N-Dots Plus personal workcenter or lie flat on
top of tool box
• Stand holds the following wrench styles:
– L- or T-shaped SAE hex 1/16–3/8ʺ (excludes AWSG and AWSBSG series) WRENCHES
– L- or T-shaped metric hex 2–10 mm (excludes AWSGM and AWSBSGM series)
®
– L- or T-shaped TORX T6 T50 (excludes AWSGT and AWSGTPT series)
• Metric or TORX on one stand
®
• SAE and metric on one stand
• Metric and SAE ball wrenches AWSTAND
Tools not included with stand.
FOLDING SETS

Hex, mm

AWMEF7K AWMEF8K AWMEF6K
A A A
1.5 45.7 — —
2 50.8 50.8 —
2.5 55.9 55.9 —
3 61.0 61.0 83.8 AWMEF6K
4 66.0 66.0 88.9
5 78.7 78.7 96.5
6 83.8 96.5 101.6 AWMEF8K
7 — 106.7 —
8 — 121.9 121.9
10 — — 129.5
AWMEF7K
AWMEF10K 10 pc Metric Folding Hex Key Set

AWEF6K AWEF9K AWTEF8K AWEFBH9K

Hex, inches TORX ® Ball Hex, inches

AWEF6K AWEF9K AWTEF8K AWEFBH9K
A A A A
5/32 2.7 0.05 1.8 T8 2.4 5/64 2.0
3/16 3.3 1/16 1.9 T10 2.7 3/32 2.1
7/32 3.5 5/64 2.0 T15 3.0 7/64 2.3
1/4 3.7 3/32 2.1 T20 3.2 1/8 2.4
5/16 4.8 7/64 2.3 T25 3.4 9/64 2.6
3/8 5.1 1/8 2.4 T27 3.5 5/32 2.7
9/64 2.6 T30 3.7 3/16 2.9
5/32 2.7 T40 3.9 7/32 3.5
3/16 2.9 1/4 3.7
®
AWEF11K 11 pc SAE Folding Hex Key Set AWTEF11K 11 pc TORX Folding AWEFBH11K 11 pc SAE Folding Hex
Hex Key Set Ball Key Set
AWMEFBH10K 10 pc Metric Folding
AWCPEF16K 16 pc Metric/SAE Folding Combination Hex Key Set
• Set includes (16 pc) AWEF9K hex set (.050–3/16ʺ) and AWMEF7K metric hex Hex Ball Key Set
set (1.5–6 mm)
317
• Plastic handle does not protect against electric shock
• Read safety precautions on pages W1 to W4
