RATCHETS

FHCNF72 FHNF100 3/8”

FN100 FZERO
FNF100
Round Head Ratchets, Chrome (3/8ʺ)
®
Snap-on Round Head Ratchets feature up to 100 teeth to achieve the lowest possible
swing arc. Slim design is perfect for the tightest of space constraints. DRIVE
Stock No. Description Gear Teeth Swing Arc A B C Repair Kit
FHCNF72* Compact Round Head Soft Grip Swivel 72 5 7/16 1-1/4 6-7/8 RKRFHCNF72
FHNF100* Red Soft Grip Swivel Head Ratchet 100 3.6 11/16 1-3/4 12-1/2 RKRFHNF100
FN100 Round Head Ratchet 100 3.6 11/16 1-3/4 7-7/8 RKRFHNF100
FNF100 Round Swivel Head Ratchet 100 3.6 11/16 1-3/4 10-1/4 RKRFHNF100
FZERO Standard Gearless Round Head Ratchet Zero 0 5/8 1-1/2 7-1/2 RKRFZERO
®
®
ASME /ANSI B107.10
*FH936-12 Soft Grip Replacement Handle Colors Available
Red Orange Green
* O G
ADD SUFFIX TO STOCK NUMBER FOR SPECIAL COLORS TOOLS

RAF80A
Low-Profile Ratchet (3/8ʺ)
Dial 80 Technology Low-Profile Ratchet
®
• Square drive design works with low-profile sockets • Dual 80 Technology requires less arc to engage
®
to access restricted clearance without loss of strength the next gear tooth
• Use with standard 3/8ʺ drive sockets • Seven teeth in contact with gear to provide strength
or other attachments and durability
• Thin handle cross section allows for increased
accessibility in tight quarters
Stock No. Description Gear Teeth Swing Arc A B C Repair Kit
RAF80A Low-Profile Ratchet 80 4.5 7/16 1-1/4 7-1/2 RKRRAF80
®
®
ASME /ANSI B107.10
FH936-12 Soft Grip Replacement Handle

F80FOD GF80FOD GFL80FOD

FOD Ratchets (Foreign Object Damage ) (3/8ʺ)
• For aviation and other critical applications where Foreign Object Damage prevention is crucial for success
• Designed to have the lowest profile and work with the shortest swing arc, providing better access to restricted areas
Stock No. Description Gear Teeth Swing Arc A B C
F80FOD Standard Handle Foreign Object Damage Ratchet 80 4.5 9/16 1-1/4 7-7/16
GF80FOD Industrial Handle Foreign Object Damage Ratchet 80 4.5 9/16 1-1/4 7-7/16
GFL80FOD Long Industrial Handle Foreign Object Damage Ratchet 80 4.5 9/16 1-1/4 10-5/16
ASME /ANSI B107.10
®
®

169
• Do not use “cheater bars” on handles
• Read safety precautions on pages W1 to W4
