RATCHETS

Low-Profile Ratchets (11 mm Internal Hex Drive) 1/4”
• Square drive design works with low-profile sockets to access restricted RAT72A
clearance areas without loss of strength
• Thin handle cross section allows for increased accessibility in tight quarters
®
• Dual 80 Technology requires less arc to engage the next gear tooth
• Six teeth in contact with gear to provide strength and durability
Stock No. Description Gear Teeth Swing Arc A B C
RAT72A 11 mm Internal Hex Low-Profile 72 5 3/8 15/16 4-7/8

GT72FOD GTL72FOD T72FOD TL72FOD DRIVE
Foreign Object Damage (FOD) Ratchet (1/4ʺ)
• Designed to help prevent foreign object damage in sensitive work environments
• Cover plate and reverse lever permanently affixed to ratchet head with rivets to
prevent chance of small parts debris
Stock No. Description Gear Teeth Swing Arc A B C
GT72FOD Industrial Handle Foreign Object Damage 72 5 7/16 15/16 4-11/16
GTL72FOD Long Industrial Handle Foreign Object Damage 72 5 7/16 15/16 6-1/2
T72FOD Standard Handle Foreign Object Damage 72 5 7/16 15/16 4-11/16
TL72FOD Long Handle Foreign Object Damage 72 5 7/16 15/16 6-1/2
ASME /ANSI B107.10 TOOLS
®
®
Special Application Ratchets
Snap-on ratchets are put through rigorous testing to perform in the real
®
world and provide trouble-free performance that stands the test of time TFY72
®
Snap-on ratchets are designed to have the lowest profile and work with the
shortest swing arc, providing better access to restricted areas
• Dual 80 Ratchet Technology features dual pawls and a 72 tooth gear
®
providing for more power in less lateral space TY72
• Six teeth in full contact with gear to provide strength and durability
• A mere 5° ratcheting arc
• Sealed head keeps dirt and other contaminants out of the head mechanism
• For use with standard or Hi-Lok sockets
®
Stock No. Description Gear Teeth Swing Arc A B C
®
TFY72 Standard Handle Hi-Lok Flex Head 72 5 7/16 15/16 6-1/4
TY72 Standard Handle Hi-Lok ® 72 5 7/16 15/16 4-5/8
®
®
ASME /ANSI B107.10
TMS70A TM77
Ratchet Spinners (1/4ʺ) Ratchet Adaptor, Chrome (1/4ʺ)

Stock No. Description A B Stock No. Description Gear Teeth Swing Arc A B
TMS70A Spinner 1 7/8 TM77 20-Tooth Adaptor 20 18 15/16 1-5/8
ASME /ANSI B107.10 ASME /ANSI B107.10
®
®
®
®
BREAKER BARS
TM9G
TM10G
THBB10
Breaker Bars, Chrome (1/4ʺ)

Stock No. Description A B C Repair Kit
TM10G 1/4ʺ Drive 6ʺ 5/8 6 5/16 RKBB1
THBB10 1/4ʺ Drive 6-1/2ʺ Soft Grip Handle 5/8 6-1/2 5/16 RKBB1
TM9G 1/4ʺ Drive 9ʺ 5/8 9 5/16 RKBB1
ASME /ANSI B107.10 129
®
®
• Do not use “cheater bars” on handles
• Do not use chrome or industrial finish hand tools with impact drivers
• Read safety precautions on pages W1 to W4
