Millimess 1002 Z/1002 ZT/1003 Z/1003 ZT/1004 Z/1004 ZT/1010 Z/1010 ZT

Mechanical Dial Comparator

FEATURES

• Large, high contrast dial face
• Adjustable tolerance markers
• Lockable fine adjustment screw
• Shockproof movement
• Mounting shank and measuring
spindle are both made of hard-
ened stainless steel
• Measuring spindle is mounted in
a high precision ball guide for
minimal hysteresis
• Resistant to lateral forces (side
play) acting on the measuring
spindle
• Maximum sensitivity and accura-
cy are ensured by the jeweled
movement in conjunction with
the precision gears and pinions
• Box type protective housing TECHNICAL DATA
• Constant measuring force Order no. 4335900 4335905 4334900 4334905 4333900 4333905 4332900 4332905
• Measuring spindle can be re- Product type 1002 Z 1002 ZT 1003 Z 1003 ZT 1004 Z 1004 ZT 1010 Z 1010 ZT
tracted with either a screw in
cable release or with a lifting Measuring range inch ± .0010” ± .0020” ± .0050” ± .0100”
knob Graduation value inch .00002’’ .00005” .0001’’ .0005”
• Package contains: case, adapt- Type of dial face .001”– 0– .001” .002”– 0– .002” .005”– 0– .005” .01”– 0– .01”
er bush 940, 8 mm to 3/8” Error limit G e inch .00002” .00005” .0001” .00035”
Error limit G ges inch .00003” .00006” .00012” .0004”
Error limit G inch .000014” .000035” .00005” .00025”
t
Hysteresis f u inch .00001” .000025” .00003” .0001”
Repeatability f w inch .00001” .000025” .00003” .0001”
Standard Factory standard
Overtravel mm 2.5
Measuring force N 1
Scale diameter mm 50
Dial color White
IP protection category: IP 54 IP 54 IP 54 IP 54

20
Order no. Mounting shaft Scale diameter 63 18
mm mm 8
957
4335900 8 50
4335905 8 50
4334900 8 50
4334905 8 50
4333900 8 50
4333905 8 50 95
4332900 8 50 954
4332905 8 50

20 .375"
ø8h6
ø4 940
951 6 10 12 970 M 2,5
ACCESSORIES
Order no. Product name Product
21 type
12
8
4310103 Adapter bushing (.375” / 8 mm) 940
4372000 Cable release (250 mm) 951
ø6,5 45 4372030 Lifting knob 954
4373030
Splash guard cover
957
15 4334786 Rubber bellows 970
4375002 Lug back to mount on mounting shank 8h6 mm 963
ø8H7
963
