MarTest 801 SL / 801 SGL

Test Indicator

FEATURES

With long stylus, for measure-
ments at poorly accessible measu-
ring points
• High-contrast dial face,
sealed with O-ring
• Mineral glass viewing panel
for best protection:
- against cracking, scratching or
damage caused by hot
shavings
- optimum resistance to solvents
Application:
• Matt chrome-plated protective
casing with three integrated
dovetail guide rails • Measurement of concentricity, alignment, parallelism and flatness
• Shockproof measuring • Centering of bores and shafts
mechanism • Parallel or perpendicular alignment of work pieces
• Anti-magnetic model
• Automatic adjustment to the
contacting direction ensuring TECHNICAL DATA
infallible readings
• Ball bearing mounted Order no. 4306950 4306960
double lever Product type 801 SL 801 SGL
• Friction clutch overload Measuring range inch ± .010”
protection
• Package contains: case, Graduation value inch .0005”
instruction manual, spanner for Scale diameter inch 1.1” 1.5”
changing the styli, stylus dia. Type of dial face 10– 0– 10
ø 2 mm, mounting shaft Dial color Green
800a3/8 Measuring force N 0.07
Range per rev. inch .02”
Deviation range f inch .0004”
e
Total deviation range f ges inch .0005”
Hysteresis f inch .0002”
u
Partial measuring span f inch .0002”
t
Repeatability f w inch .0001”
Standard Factory standard
Order no. a b c d e f Measuring anvil length 26 49,5
mm mm mm mm mm mm mm
17
4306950 30 40.3 44.6 102 126 41.24
4306960 40.5 40.3 44.6 102 126 41.24 øb
øa
126 f
102 e 8
110°
d
c
ø 2 9
ACCESSORIES
Order no. Product name Product
type

4306851 Stylus ø 1.0 mm, carbide, l = 41.24 mm 800 tl
4306850 Stylus ø 2.0 mm, carbide, l = 41.24 mm 800 tl
4306853 Stylus ø 3.0 mm, carbide, l = 41.24 mm 800 tl
4309053 Stylus ø 2.0 mm, ruby, l = 41.24 mm 800 tlr
4305868 Spanner
l
M2 d

800 tb;800 tbr;800 te;800 ter;800 tl;800 tlr;800 ts;800 tsr;801 tl
