P. 163
97
49
货号 mm² AWG mm Ø mm
2.8 mm 0.1 - 0.25
97 49 04 2.8mm 4.8mm 2.8 mm 0.5 - 1 27 - 13
4.8 mm 0.5 - 1
4.8 mm 1.5 - 2.5
0.5 - 1
97 49 05 4.8mm 6.3mm 1.5 - 2.5 20 - 10
4 - 6
0.5 - 1
97 49 06 1.5 - 2.5 20 - 10
4 - 6
0.5 - 1
97 49 07 1.5 - 2.5 20 - 10
4 - 6
0.25 - 0.75
1 - 1.5
97 49 08 2.5 23 - 10
4
6
97 49 09 10 / 16 / 25 7 / 5 / 3
0.75 / 1.5 / 2.5 13
97 49 10 DIN 46237 DIN 46341 0.5 - 0.75 15 - 17
19 - 20
97 49 11 DIN 46235/DIN 46267 4 / 6 / 10 7 / 10 / 11
0.5 - 1
1.5 - 2.5
97 49 14 DIN 46235/DIN 46267 4 - 6
10
6.3 mm 1.25 - 2.5
97 49 15 4.8mm 6.3mm 4.8 mm 3 - 4 17 - 13
4.8 mm 4 - 6 17 - 10
10
97 49 16 7 / 5
16
2×10
97 49 18 2×6 / 2×10 / 2×16 2×7
2×5
97 49 19 35 / 50 2 / 0
97 49 20 7.0 / 8.4 / 8.1 7.7 / 9.5 /
9.5
97 49 23 16 + 25 5 + 3
0.03 - 0.09
97 49 24 D-Sub; HD 20; HDE plugs 0.2 - 0.56 32 - 20
0.08 - 0.2
97 49 25 Micro-Fit™ 0.35 - 0.75 / 0.5 - 1.0 / 0.2 - 0.5 20 / 22-24 / 26-30
97 49 26 Mini-Fit ® 16 / 18 / 20-24
97 49 27 MQS-Stecker 0.25 / 0.35 / 0.5
97 49 30 DIN 46267 1.5 - 4 15 - 11
160
