Torque Technology Torque Technology

Pictogram key

ö Width in mm $ TRACTION PROFILE h Inside hexagon
6-point
ä Height in mm % TRACTION PROFILE g Outside hexagon
12-point
l Length in mm 6 1 Nominal size 6.3 B Female connection 9 x 12 mm
in torque wrenches
s Wrench size in mm or inches 7 2 Nominal size 10 D Female connection 14 x 18 mm
in torque wrenches
r h Size in mm 8 3 Nominal size 12.5 f Number of teeth

# Actuating force in kg 9 4 Nominal size 20 . ° Rotation angle
b For inside hexagon screws 0 5 Nominal size 25 Å Scale graduation
c For outside hexagon screws j Inside square

N For inside h screws i Outside square

The HAZET Service Centre

Direct contact and coordination point for services
for all of our products

• In our specially equipped Service Centre, you can receive
the best aftersales service with short response
times and the complete HAZET competence.
• Mainly the HAZET Service Centre provides
you with the following services:
– Repair, adjustment, calibration and certification of
HAZET torque wrenches
– All service tasks on HAZET torque wrenches,
pneumatic tools, tool trolleys and the rest of the
catalogue programme
– Short response times
– Contact partner in service matters

Made in Germany
258 Valid until December 31, 2021 Components and spare parts from page 482 to 490
