Hand Tools

Thread repair

844 Stud extractor set 842 AIG Universal thread repair tool set

Made in Germany S/ 8 • For outside thread 4–13 mm ( ⁄12″ – ⁄2″) and
1
5
1
13
• SmartCase (1/9) 165-S inside thread 5–12 mm ( ⁄64″ – ⁄2″)
• Safety-Insert-System, 2-component soft foam insert.
Insert also suitable for HAZET Assistent • Application: Repairing right-hand and left-hand threads
• Surface: chrome-plated, polished (all forms of metric and non-metric threads)
• Simple and quick fixation due to knurled screw
• Also for aluminium threads
• 1 tool for outside threads
• 2 tools for inside threads
• Protective covers for
aluminium threads

1 è 4
844 • 8
844-6 • 844-7 • 844-8 842 AIG-1/4 4 153428
844-10 • 844-12
1 L x W x H è 4 842 N Thread repair tool set
mm
844/5 185 x 153 x 52 5 035878 • Thread reinforcement of materials presenting a low shearing resistance.
Application in machine construction, automotive engineering,
electrical and medical engineering, for example
842 AG Universal thread repair tool • Chrome-nickel stainless steel provides good inside threads
resisting the influences of weathering and corrosion
• Plastic box
5
1
• For thread diameters 4 – 13 mm ( ⁄32″ – ⁄2″)
• Application: Repairs right-hand and left-hand threads (observe
direction of rotation)
All forms of metric and non-metric
threads (60° flank measurement)
• Quick fixation due to adjusting screw
• Blade automatically adapts to any
thread pitch within range

1 R 4
842 AG-1 4 – 13 mm / ⁄32″ – ⁄2″ 140718
5
1
5
1
• For thread diameters 16 – 38 mm ( ⁄8″ – 1. ⁄2″) S
• Application: Trimming right-hand and left-hand threads (observe
direction of rotation)
all forms of metric and non-metric
threads (60° flank measurement)
• Quick fixation due to adjusting screw
• Blade automatically adapts to
any thread pitch within range
1 è 4

• 118-piece set, M 6 to M 14
• M 14 especially for spark plug thread
• Contents:
25 threaded inserts each
M6 x 1.00 mm x 9.0 mm
M8 x 1.25 mm x 12.0 mm
M10 x 1.50 mm x 15.0 mm
• 10 threaded inserts M 12 x 1.75 mm x 18.0 mm
• 5 threaded inserts each
M14 x 1.25 mm x 8.4 mm
M14 x 1.25 mm x 12.4 mm
1 R 4 • 4 twist drills, 5 thread cutters, 5 assembly tools, 4 pin breaking tools
M14 x 1.25 mm x 16.4 mm
842 AG-3 16 – 38 mm / ⁄8″ – 1. ⁄2″ 149230 842 N-614/118 118 167272
5
1
