Page 196 - HAZET英文2021

Hand Tools

Screwdrivers / Bits

2225 5-star bit Wear? – No problem!
C • HAZET tools are manufactured to the highest
UF quality. During long intensive loading there is a
certain level of wear even for high-quality tools.
1 K 4 • For this reason, there are spare parts and
2225-10 H 25 097043 replacement sets available for many of our tools.
2225-15 H 25 097050
2225-20 H 25 097067
2225-25 H 25 097074
2225-27 H 25 097081
2225-30 H 25 097098 Cost-saving – Sustainable – Resource-saving!
2225-40 H 25 097104 For long-term pleasure with your HAZET tools

863-Bit Reversible ratchet ∙ solid steel ∙ for bits

Made in Germany S/ E 863 Replacement set
• 89 mm short style
Made in Germany
• Sturdy design in short, slim form • Number of teeth: 20
• Ergonomic finger support on the end of the handle • Opening angle: 18°
• Number of teeth: 20
• Opening angle: 18°
• Angled at 15° to reduce risk of entrapment
• With locking spring to securely hold the bits
• Surface: chrome-plated

1 4

1 K 4 • Replacement set for shift lever consisting of:
shift lever ∙ pawl ∙ screws ∙ ball ∙ compression spring
For HAZET reversible ratchet 863 K ∙
863 M Bit 89 196111 863 ∙ 863 G ∙ 863 P ∙ 863 PC ∙ 863 Q ∙ 863 S ∙ 863 ST ∙ 863 BGL ∙
863 BKC ∙ 863 BK ∙ 863 MC ∙ 863 Mbit ∙ 2264
Reversible ratchet for 863 P/6 144600
863-Bit screwdriver bits ∙ fine-tooth • Replacement set for ratchet wheel h 6.3 = ⁄4″ consisting of:
1
ratchet wheel ∙ pawl ∙ shift lever ∙ screws ∙ ball ∙ compression spring
Made in Germany S E For HAZET reversible ratchet 863 BGL ∙
• A lot more power than with ratchets with the same dimensions 863 BKC ∙ 863 BK ∙ 863 MBit ∙ 2264
2264/7 015917
• Engaging function of the shift lever provides
protection against unwanted switching
• Longer lifetime by using the latest lubricants in the ratchet mechanism 810 BH Bit holder
• Close manufacturing tolerances prevent dirt from getting in
• HAZET internal quality standards guarantee a loading • Bayonet fitting E
capacity far beyond standard requirements
• Chrome-plated surface: high-quality, easy to clean, corrosion-resistant • Versatile and flexible for home and workshop
• Integrated hanging option in the handle • Perfect for supplementing with HAZET bit sets
• VPA tested, static torque according to DIN 3122: 120 Nm (DIN: 62 Nm) • No annoying rolling away thanks to special design
• Number of teeth: 90 • Non-slip HAZET 3-component handle –
• Opening angle: 4° allows high power transmission
• With locking spring to securely hold the bits
• HAZET 2-component handle
• Surface: chrome-plated

1 M N 4
810 BH 22.5 132.5 217175

1 K 4
863 HP B 116 235346

Components and spare parts from page 482 to 490 Valid until December 31, 2021 195
