Two-stage high-power heater. RoHS POWER LAMP (TQ-77 ONLY) COMFORTABLE SOLDERING SYSTEM SOLDERING
Easy heater-on check
QUICK-HEAT SOLDERING IRONS 2 TWO-STAGE HEAT-SWITCH SYSTEM High-power ceramic heater
ERGONOMIC GRIP
TQ-77/95 10 times higher power than normal Prevents fatigue HIGH-EFFICIENCY SOLDERING IRONS

TQ-95

Power monitor lamp
QUICK-HEAT BUTTON
Controls power
trigger

Specially processed
long-life tip
TQ-77
Heat-resistant cap for quick AUTOMATIC
storage after use. SOLDER FEEDER
SPECIFICATIONS REPLACEMENT TIPS
Model TQ-77 TQ-95 TQ-77RT-SB (110-130V) TQ-77RT-B (110-130V) TQ-77RT-BC (110-130V)
Voltage 110-130 V, 220-240 V AC 50/ 60 Hz TQ-77RT-SB-L (220-240V) TQ-77RT-B -L (220-240V) TQ-77RT-BC -L (220-240V)
17
High 150 W / Low 15 W (110-130 V model) 12.5 17 13 45˃ 13 17 TIP THERMOMETER
Power Consumption П5.5 6 П5.5 6 П5.5 SOLDERING TESTER
High 200 W / Low 20 W (220-240 V model) 6
Insulation Over 100 MΩ (500 V DC) П4 R0.3 R0.5
Resistance TQ-77RT-2C (110-130V) TQ-77RT-3C (110-130V)
Heater Ceramic Heater TQ-77RT-2C-L (220-240V) TQ-77RT-3C-L (220-240V)
Power Cord Length 1.5 m 45˃ 10 17 45˃ 10 17
Length 167 mm 210 mm П5.5 6 П5.5 6 SOLDER POTS
Weight 90 g 65 g П2.1 П3
Soldering Iron Tip (TQ-77RT-B)
Accessories Soldering Iron Tip (TQ-77RT-B)
Cap for TQ-95 (TQ-CAP) Overall View Collar Heater Barrel
38 (48) TQ-77/95 Spacer Heater
*The length does not include the cord bushing. The weight does not include the cord. П5.5 П7.3 Tip
NOTE: High power runs while trigger/quick button is pressed.
( ) Size for 220-240 V AC model / SMT PRODUCTS SURFACE-MOUNT
REPLACEMENT PARTS / OPTIONS
TQ-95Heater TQ-77 Heater TQ-77/95 Spacer TQ-95 Heat-Resistant Cap Recommended Stand
TQ-95H TQ-77H TQ-77SS TQ-CAP ST-27
TQ-77/95 Heater Barrel TQ-77/95 Collar
TQ-77HP(L) 220-240 V TQ-77NUT PRODUCTS
TQ-77HP(S) 110-130 V DESOLDERING
Best for precision soldering. SPECIFICATIONS
PRECISION PCB SOLDERING IRONS Model CS-21 CS-31
CS-21/31 Voltage 110 V, 220 V, 240 V AC 50/ 60 Hz 110V, 120V, 220V, 240V AC 50/ 60 Hz ACCESSORIES SOLDERING
25 W
20 W
Power Consumption
Insulation Resistance Over 100 MΩ (500 V DC)
Heater Ceramic Heater
Power Cord Length 1.5 m
RoHS Length 188 mm
2 Weight 43 g
CS-31 Accessories Soldering Iron Tip (CS-20/30RT-SB) MATERIALS SOLDERING WORK
*The length does not include the cord bushing. The weight does not include the cord.

CERAMIC-PIPE HEATER
Lower priced tips REPLACEMENT TIPS
PERFECT FOR PRECISION SOLDERING CS-20/30RT-SB CS-20/30RT-SBC HEATED TOOLS
Slim and sharp tips 14.5 25.5 15 25.5
R0.25
П 3 1 П 3
SLIM GRIP
Easy to hold CS-20/30RT-2C CS-20/30RT-3C
REPLACEMENT PARTS / OPTIONS 15 25 15 25
П 3 П 3
CS-21 Heater Recommended Stand П 2 П 3 HAND TOOLS
CS-21H ST-27
CS-31 Heater
CS-31H
