P. 260
PROFESSIONAL PLUS STANDARD
VDE wire stripping pliers
Art.-Group 155
▶ Highest safety while working with electrical systems according to
DIN EN 60900 and IEC 900
▶ Also safe in case of extreme operating conditions due to certified
stability at -40°C
▶ For stripping solid, stranded or finely stranded conductors with
standard insulation
▶ With V-shaped cutting edge for wires and strands up to a max. of
Ø 5 mm or 10 mm² wire diameter
▶ With adjustable screw for easy setting the required wire or
strand diameter
▶ Made of tool steel, forged, oil hardened
▶ Handles with ergonomically shaped multi-component safety
sleeves according to DIN EN/IEC 60900
▶ With opening spring to open the edges
Material Tool steel, forged, oil hardened
Coating Chrome-plated and matt-satin finish
Handle 2-components-plastic
Norm DIN EN 60900 / IEC 900
Without packaging
Length €/Pc. Art.-No.
160 mm 38.70 4 627-160
PROFESSIONAL PLUS STANDARD
VDE multi cutter 3-in-1
Art.-Group 155
▶ Multifunctional wire stripping pliers with 3 functions in one tool:
cut off, strip cable, strip wire
▶ Highest safety while working with electrical systems according to
DIN EN 60900 and IEC 900
▶ Handles with ergonomically shaped multi-component safety
sleeves according to DIN EN/IEC 60900
▶ Also safe in case of extreme operating conditions due to certified
stability at -40°C
▶ Power transmission with optimum leverage for easy and
effortless work
▶ With cable stripper function for all common cables ranging from
Ø 8 mm to Ø 13 mm
VDE
▶ With V-shaped cutting edge for wires and strands up to a max. of
Ø 5 mm or 10 mm² wire diameter
▶ Precision edge for finest wires
▶ Induction hardened cutting edges to extend the range of
application as well as the lifetime
▶ For precise, quick and safe stripping of all common round cables
▶ Side cutter for cutting hard and soft wires
Material Tool steel, forged, oil hardened
Coating Chrome-plated and matt-satin finish
Handle 2-components-plastic
Norm DIN EN 60900 / IEC 900
Without packaging
Length €/Pc. Art.-No.
200 mm 61.50 4 630-180
