PLUS

PROFESSIONAL

PROFESSIONAL PLUS STANDARD
STANDARD

Xi-on socket metric 6.3 [1/4"]
Art.-Group 125

▶ If nothing works anymore, Xi-on does the job!
▶ Extremely innovative: revolutionary Xi-on construction opens even t
up to 85% rounded screws and nuts
▶ Opens all standard metric hex, 12-point, spline nuts and screws
▶ Easy working even where conventional sockets will fail D1 D2
▶ Recommended by »Technik und Motor« of FAZ (established
reputable Frankfurt Newspaper, Germany)
▶ Exact fit and highest power transmission with less wear
▶ High grip due to the circumferential knurling L

Version Short Drive Size 6.3 [1/4"]
Material Chrome-vanadium steel Locking Drive Ball catch groove
Coating Chrome-plated and matt satin finished, with knurling Output Outside hexagon
Application Type Manually operated Norm DIN 3120 / ISO 1174
Drive Internal square according to DIN 3120 / ISO 1174
Plastic hanger
Size L mm D1 mm D2 mm t mm €/Pc. Art.-No. Size L mm D1 mm D2 mm t mm €/Pc. Art.-No.
4 25 6.7 11.8 3.5 2.85 411 004 8 25 11.8 11.8 6.0 2.85 411 008
4.5 25 7.3 11.8 3.5 2.85 411 045 9 25 12.8 12.0 6.0 2.85 411 009
5 25 8.0 11.8 4.0 2.85 411 005 10 25 14.8 12.0 7.0 2.85 411 010
5.5 25 8.6 11.8 4.0 2.85 411 055 11 25 15.8 14.0 8.0 3.01 411 011
6 25 9.2 11.8 4.5 2.85 411 006 12 25 16.9 14.0 9.0 3.01 411 012
7 25 10.7 11.8 6.0 2.85 411 007 13 25 17.9 14.0 9.0 3.33 411 013

PLUS

PROFESSIONAL
STANDARD

PROFESSIONAL PLUS STANDARD
Xi-on bit socket for slotted screws 6.3 [1/4"]
Art.-Gruppe 125

▶ Sockets for slotted screws
▶ Highest quality level for demanding users
▶ Exact fit and highest power transmission with less wear
▶ Optimized to durability and highest demands
▶ Precision and durability far beyond DIN/ISO standards
▶ High grip due to the circumferential knurling

Version Short Drive Size 6.3 [1/4"]
Material Chrome-vanadium steel / S2 steel Locking Drive Ball catch groove
Coating Chrome-plated and matt satin finished, with knurling Output For slotted screws
Application Type Manually operated Norm DIN 3120 / ISO 1174
Drive Internal square according to DIN 3120 / ISO 1174
Plastic hanger
Size L1 mm L2 mm D1 mm €/Pc. Art.-No. Size L1 mm L2 mm D1 mm €/Pc. Art.-No.
5.5 32 12 11.0 3.93 411 255 7 32 12 11.0 3.93 411 207

H 123
