P. 602
HSSTINSPIBO
钢质箱装HSS-G Co 5 麻花钻套装 HSS TIN TWIST DRILLS
330.4050 5.0 86.0 52.0 10 100
• 带集成封闭
• 高强度的铰链 330.4051 5.1 86.0 52.0 10 130
• DIN 338 Typ N HSS TiN 板牙 330.4052 5.2 86.0 52.0 10 130
• 右切 330.4053 5.3 86.0 52.0 10 130
• 锥形磨头用作点磨 • DIN 338 Typ N 330.4054 5.4 93.0 57.0 10 130
• 交叉磨光 • 右切 330.4055 5.5 93.0 57.0 10 130
• 130° 锐角 • 锥形磨头用作点磨
• 20 - 30° 螺旋角 • 交叉磨光 330.4056 5.6 93.0 57.0 10 150
• 高耐热性 • 130° 锐角 330.4057 5.7 93.0 57.0 10 150
• 最大负荷 • 20 - 30° 螺旋角 330.4058 5.8 93.0 57.0 10 150
• 金黄色表面 • 高耐热性 330.4059 5.9 93.0 57.0 10 150
• 钴合金高性能钢 • 最大负荷 330.4060 6.0 93.0 57.0 10 150
• 带氮化钛涂层表面 330.4061 6.1 101.0 63.0 10 180
可用于高达 1100 N /mm²强度的非合金钢和合金钢, 回火和表 • 高性能钢
面硬化钢, 不锈钢和耐酸钢以及冷热作业钢 330.4062 6.2 101.0 63.0 10 180
非常适合用于高达 900 N/mm²强度的钢, 合金和非合金铸钢, 330.4063 6.3 101.0 63.0 10 180
青铜, 黄铜, 短切削铝合金, 石墨, 镍银, 烧结铁, 灰色, 回火, 结 330.4064 6.4 101.0 63.0 10 180
节和压铸。 330.4065 6.5 101.0 63.0 10 180
330.4066 6.6 101.0 63.0 10 250
330.4067 6.7 101.0 63.0 10 250
330.4068 6.8 109.0 69.0 10 250
330.4069 6.9 109.0 69.0 10 250
330.4070 7.0 109.0 69.0 10 250
330.4071 7.1 109.0 69.0 10 260
330.4072 7.2 109.0 69.0 10 260
330.4073 7.3 109.0 69.0 10 260
330.4074 7.4 109.0 69.0 10 260
330.4075 7.5 109.0 69.0 10 260
330.4076 7.6 117.0 75.0 10 330
330.4077 7.7 117.0 75.0 10 330
330.4078 7.8 117.0 75.0 10 330
330.4079 7.9 117.0 75.0 10 330
330.4080 8.0 117.0 75.0 10 330
330.4081 8.1 117.0 75.0 10 350
330.4082 8.2 117.0 75.0 10 350
330.4083 8.3 117.0 75.0 10 350
330.4084 8.4 117.0 75.0 10 350
330.4085 8.5 117.0 75.0 10 350
330.4086 8.6 125.0 81.0 10 430
per 10 x: 330.4087 8.7 125.0 81.0 10 430
1,0 - 1,5 - 2,0 - 2,5 - 3,0 - 3,5 - 4,0 330.4088 8.8 125.0 81.0 10 430
330.3640 170件 - 4,5 - 5,0 - 5,5 - 6,0 - 6,5 - 7,0 4.15 330.4089 8.9 125.0 81.0 10 430
- 7,5 - 8,0
per 5 x: 330.4003 0.3 19.0 3.0 10 1 330.4090 9.0 125.0 81.0 10 430
8,5 - 9,0 - 9,5 - 10,0 mm
330.4004 0.4 20.0 5.0 10 1 330.4091 9.1 125.0 81.0 10 480
330.4005 0.5 22.0 6.0 10 1 330.4092 9.2 125.0 81.0 10 480
钢质箱装HSS-G Co 5 麻花钻套装 330.4006 0.6 24.0 7.0 10 1 330.4093 9.3 125.0 81.0 10 480
330.4007 0.7 28.0 9.0 10 1 330.4094 9.4 125.0 81.0 10 480
• 带集成封闭 330.4008 0.8 30.0 10.0 10 1 330.4095 9.5 125.0 81.0 10 480
• 高强度的铰链 330.4009 0.9 32.0 11.0 10 1 330.4096 9.6 133.0 87.0 10 275
• DIN 338 Typ N
• 右切 330.4010 1.0 34.0 12.0 10 1 330.4097 9.7 133.0 87.0 10 275
• 锥形磨头用作点磨 330.4011 1.1 36.0 14.0 10 1 330.4098 9.8 133.0 87.0 10 275
• 交叉磨光 330.4012 1.2 38.0 16.0 10 1 330.4099 9.9 133.0 87.0 10 275
• 130° 锐角 330.4013 1.3 38.0 16.0 10 1 330.4100 10.0 133.0 87.0 5 275
• 20 - 30° 螺旋角 330.4014 1.4 40.0 18.0 10 1 330.4101 10.1 133.0 87.0 5 300
• 高耐热性
• 最大负荷 330.4015 1.5 40.0 18.0 10 1 330.4102 10.2 133.0 87.0 5 300
• 金黄色表面 330.4016 1.6 43.0 20.0 10 10 330.4103 10.3 133.0 87.0 5 300
• 钴合金高性能钢 330.4017 1.7 43.0 20.0 10 10 330.4104 10.4 133.0 87.0 5 300
330.4018 1.8 46.0 22.0 10 10 330.4105 10.5 133.0 87.0 5 300
可用于高达 1100 N /mm²强度的非合金钢和合金钢, 回火和表 330.4019 1.9 46.0 22.0 10 10 330.4106 10.6 133.0 87.0 5 350
面硬化钢, 不锈钢和耐酸钢以及冷热作业钢
330.4020 2.0 49.0 24.0 10 10 330.4107 10.7 142.0 94.0 5 350
330.4021 2.1 49.0 24.0 10 20 330.4108 10.8 142.0 94.0 5 350
330.4022 2.2 53.0 27.0 10 20 330.4109 10.9 142.0 94.0 5 350
330.4023 2.3 53.0 27.0 10 20 330.4110 11.0 142.0 94.0 5 350
330.4024 2.4 57.0 30.0 10 20 330.4111 11.1 142.0 94.0 5 385
330.4025 2.5 57.0 30.0 10 20 330.4112 11.2 142.0 94.0 5 385
330.4026 2.6 57.0 30.0 10 40 330.4113 11.3 142.0 94.0 5 385
330.4027 2.7 61.0 33.0 10 40 330.4114 11.4 142.0 94.0 5 385
330.4028 2.8 61.0 33.0 10 40 330.4115 11.5 142.0 94.0 5 385
330.4029 2.9 61.0 33.0 10 40 330.4116 11.6 142.0 94.0 5 440
330.4030 3.0 61.0 33.0 10 40 330.4117 11.7 142.0 94.0 5 440
330.4031 3.1 65.0 36.0 10 40 330.4118 11.8 142.0 94.0 5 440
330.4032 3.2 65.0 36.0 10 40 330.4119 11.9 151.0 101.0 5 440
330.4033 3.3 65.0 36.0 10 40 330.4120 12.0 151.0 101.0 5 440
330.4034 3.4 70.0 39.0 10 40 330.4121 12.1 151.0 101.0 5 490
330.4035 3.5 70.0 39.0 10 40 330.4122 12.2 151.0 101.0 5 490
330.4036 3.6 70.0 39.0 10 50 330.4123 12.3 151.0 101.0 5 490
330.4037 3.7 70.0 39.0 10 50 330.4124 12.4 151.0 101.0 5 490
330.4038 3.8 75.0 43.0 10 50 330.4125 12.5 151.0 101.0 5 490
330.4039 3.9 75.0 43.0 10 50 330.4126 12.6 151.0 101.0 5 515
330.4040 4.0 75.0 43.0 10 50 330.4127 12.7 151.0 101.0 5 515
330.4041 4.1 75.0 43.0 10 80 330.4128 12.8 151.0 101.0 5 515
330.4042 4.2 75.0 43.0 10 80 330.4129 12.9 151.0 101.0 5 515
330.4043 4.3 80.0 47.0 10 80 330.4130 13.0 151.0 101.0 5 515
330.4044 4.4 80.0 47.0 10 80 330.4135 13.5 160.0 108.0 1 110
per 10 x: 330.4045 4.5 80.0 47.0 10 80 330.4140 14.0 160.0 108.0 1 115
1,0 - 1,5 - 2,0 - 2,5 - 3,0 - 3,2 - 3,5
- 4,0 - 4,2 - 4,5 - 5,0 - 5,5 - 6,0 - 330.4046 4.6 80.0 47.0 10 100 330.4145 14.5 169.0 114.0 1 120
330.3650 230件 6,5 - 6,8 - 7,0 - 7,5 - 8,0 7.40 330.4047 4.7 80.0 47.0 10 100 330.4150 15.0 169.0 114.0 1 125
per 5 x: 330.4048 4.8 86.0 52.0 10 100 330.4155 15.5 178.0 120.0 1 130
8,5 - 9,0 - 9,5 - 10,0 - 10,5 - 11,0 -
11,5 - 12,0 - 12,5 - 13,0 mm 330.4049 4.9 86.0 52.0 10 100 330.4160 16.0 178.0 120.0 1 135
