1360-S
THREAD CUTTING ASSORTMENT, HSS

³ 15 pcs.
³ in plastic case
³ for cutting internal threads from M3 to M12
³ consisting of bottoming tap, adjustable tap wrench and twist drill
³ according to DIN 352

Code Number Contents Pieces Weight/g
U V
1360000011000 1360-S Bottoming tap 6 660
M3x0,5, M4x0,7, M5x0,8, M6x1, M8x1,25, M10x1,5, M12x1,75
twist drill
2,5; 3,3; 4,2; 5,0; 6,8; 8,5; 10,2 , adjustable tap wrench 1.1/2"

1363-S
THREAD CUTTING ASSORTMENT, HSS
³ 51 pcs.
³ in plastic case with hard foam insert
³ for cutting internal and external threads M3 to M12
³ consisting of hand taps (3 steps), tap wrench,
twist drills, circular dies, die holder and thread gauge
³ incl. guides for circular dies
³ according to DIN 352

Code Number Contents Pieces Weight/g
U V
1363000001000 1363-S hand taps (3 steps) 1 3900
M3x0,5; M4x0,7; M5x0,8; M6x1; M8 x 1,25; M10x1,5; M12x1,75
twist drills: Ø 2,5; 3,3; 4,2; 5,0; 6,8; 8,5; 10,2
tap wrench M3 ,M4, M5, M6, M8, M10, M12
holder for circular dies
7 guides
thread gauge | screwdrivers | 2 circular dies

1363-SF
THREAD CUTTING ASSORTMENT, FINE THREAD, HSS
³ 42 pcs.
³ in plastic case with hard foam insert
³ for cutting internal and external threads Mf3 to Mf12
³ Consisting of hand taps (2 steps), tap wrench, twist drills,
circular dies, die holder, guideways and thread gauge
³ incl. guides for circular dies
³ according to DIN 352

Code Number Contents Pieces Weight/g
U V
1363000011000 1363-SF hand taps (2 steps): M3x0,35; M4x0,5; M5x0,5; M6x0,75; M8 x 1,0; M10x1; M12x1,5 1 4000
twist drills: Ø 2,6; 3,5; 4,5; 5,2; 7,0; 9,0; 10,5
2 tap wrench
circular dies Mf3 ,Mf4, Mf5, Mf6, Mf8, Mf10, Mf12
holder for circular dies
7 guides
thread gauge | screwdriver 13
